Ball mill 'MB-5'
Reference number : 5810050
The 'MB-5' Ball Mill is ideal for ultrafine grinding and mixing of materials in the laboratory or small batch production.It offers high efficiency and uniform particle size, making it applicable in industries such as electronics, biomedicine, ceramics, minerals, and more.Features:Compact structure and easy to operate.Compatible with containers of different sizes through adjustment of the rubber rollers.High grinding efficiency.Specifications:Power: 0.37 kWSpeed: 50-570 rpmMaximum load: 35 kgContainer volume: 2-5 L

Technical section
| Name | Value |
|---|---|
| Motor Power (KW) | 0.37 |
| Tall x ancho x bottom (cm) | 26 x 73 x 42 |
| Rotation speed | 50 - 570 r/min |
| Space between rollers (mm) | 250 |
| Maximum working load per container (kg) | 35 |
| Volume of containers (L) | 2-5 |
Documents
- Manual de usoDownload
