Ball mill 'MB-5'

Reference number : 5810050

The 'MB-5' Ball Mill is ideal for ultrafine grinding and mixing of materials in the laboratory or small batch production.
It offers high efficiency and uniform particle size, making it applicable in industries such as electronics, biomedicine, ceramics, minerals, and more.
Features:
Compact structure and easy to operate.
Compatible with containers of different sizes through adjustment of the rubber rollers.
High grinding efficiency.
Specifications:
Power: 0.37 kW
Speed: 50-570 rpm
Maximum load: 35 kg
Container volume: 2-5 L

Technical section

NameValue
Motor Power (KW)0.37
Tall x ancho x bottom (cm)26 x 73 x 42
Rotation speed50 - 570 r/min
Space between rollers (mm)250
Maximum working load per container (kg)35
Volume of containers (L)2-5

Documents
