Microscopio binocular '206 LED Polarizable'

Reference number : 5313115

The binocular microscope '206 LED Polarizable' is ideal for bright field, dark field, polarization, and phase contrast techniques, suitable for studies in areas such as biology and clinical research.
It has a head inclined at 30° with 360° rotation, achromatic objectives of 4x, 10x, 40x, and 100x, and magnifications of up to 1600x.
It includes an Abbe condenser with 1.25 N.A. and a stage of 160x140 mm with micrometric and macrometric focusing.
The illumination is 3W LED with integrated polarizer and analyzer, and its weight is 7.5 kg.

Technical section

NameValue
High / Width / Fund (mm)425 x 245 x 335
Voltage220V / 50 Hz
Weight (kg)7,5
