Vacuum membrane pump 'N-86'
Reference number : 5910106
The N-86 diaphragm vacuum pump (reference 5910106) is ideal for transfer and evacuation without contamination.It has a flow rate of 5.5 l/min, with a vacuum limit of 160 mbar and a relative pressure of 2.5 bar.Its connections have an inner diameter of 4 mm.It is constructed with PPS (polyphenylene) heads and phases, Teflon membranes, and FFPM valves.Its sealing rate is 6x10⁻³ mbar x L/s.It operates with a power consumption of 0.63 W and weighs 1.9 kg.It withstands operating temperatures from 5 to 40°C, with IP-20 protection.
Technical section
| Name | Value |
|---|---|
| Vacuum flow (at 1 pressure atm) | 5,5 l/min 0,33 m³/h |
| Absolute limit (mbar) | 160 |
| Relative pressure (bar) | 2,5 |
| For rabbit to Ø interior tube (mm) | 4 |
| Number of heads and phases | 1 |
| Head material | PPS |
| Membrane material (diaphragms) | teflonated |
| Valve material | Ffpm |
| Motor protection degree | IP-20 |
| Permissible Gase and Environmental Operating Temperature | 5 a 40ºC |
| Consumption (a) / power (W) | 0,63 / 65 |
| Dimensions (high x width x background) (cm) | 14 x 9 x 17 |
| Weight (kg) | 1,9 |
Documents
- User manualDownload
