Vacuum Pump 'Ivymen-20'

Reference number : 5900620

The rotary vane vacuum pump model 5900620 has a flow rate of 3.6 m³/h and a vacuum limit of 0.1 mbar.
It is equipped with an analog vacuum gauge and a 250 ml oil reservoir, with forced lubrication for greater efficiency.
The suction port has a diameter of 16 mm, and the pump operates at a low noise level of 62 dB, with a maximum working temperature of 40°C.
Its power consumption is 120 W, and it weighs 7.6 kg, making it portable and easy to transport thanks to its integrated handle.

Technical section

NameValue
Vacuum flow m³/h3,6
Empty mbar limit0,1
High / Width / Fund (Exterior) (CM)23 x 27 x 12
r.p.m1400
Consumo (W)120
Weight (kg)7,6
