Vacuum Pump 'Ivymen-20'
Reference number : 5900620
The rotary vane vacuum pump model 5900620 has a flow rate of 3.6 m³/h and a vacuum limit of 0.1 mbar.It is equipped with an analog vacuum gauge and a 250 ml oil reservoir, with forced lubrication for greater efficiency.The suction port has a diameter of 16 mm, and the pump operates at a low noise level of 62 dB, with a maximum working temperature of 40°C.Its power consumption is 120 W, and it weighs 7.6 kg, making it portable and easy to transport thanks to its integrated handle.

Technical section
| Name | Value |
|---|---|
| Vacuum flow m³/h | 3,6 |
| Empty mbar limit | 0,1 |
| High / Width / Fund (Exterior) (CM) | 23 x 27 x 12 |
| r.p.m | 1400 |
| Consumo (W) | 120 |
| Weight (kg) | 7,6 |
Documents
- User guideDownload
